CRLB Optimization for O-RIS-Assisted VLP Systems

ZHANG Zengjie; WU Qi; ZHANG Jian; DUAN Ruijie; FENG Yunhan

doi:10.11999/JEIT260120

Volume 48 Issue 8

Aug. 2026

Turn off MathJax

Article Contents

Article Navigation > Journal of Electronics & Information Technology > 2026 > 48(8): 3296-3305

ZHANG Zengjie, WU Qi, ZHANG Jian, DUAN Ruijie, FENG Yunhan. CRLB Optimization for O-RIS-Assisted VLP Systems[J]. Journal of Electronics & Information Technology, 2026, 48(8): 3296-3305. doi: 10.11999/JEIT260120

Citation:

ZHANG Zengjie, WU Qi, ZHANG Jian, DUAN Ruijie, FENG Yunhan. CRLB Optimization for O-RIS-Assisted VLP Systems[J]. Journal of Electronics & Information Technology, 2026, 48(8): 3296-3305. doi: 10.11999/JEIT260120

Citation:

PDF( 3582 KB)

CRLB Optimization for O-RIS-Assisted VLP Systems

doi: 10.11999/JEIT260120 cstr: 32379.14.JEIT260120

Information Engineering University, Zhengzhou 450007, China

Funds: The National Natural Science Foundation of China (62571549, 62331024, 62271505)

Received Date: 2026-01-30
Accepted Date: 2026-04-23
Rev Recd Date: 2026-04-23

Available Online: 2026-05-16

Publish Date: 2026-08-01

Abstract

Abstract

Objective Visible Light Positioning (VLP) has become a promising high-accuracy technology for indoor location-based services. Optical Reconfigurable Intelligent Surface (O-RIS) technology can improve signal coverage and positioning performance in VLP systems. However, positioning accuracy and spatial fairness remain difficult to optimize in O-RIS-assisted VLP systems. This study optimizes the Cramer-Rao Lower Bound (CRLB) under both near-field and far-field channel models. The aim is to improve overall positioning accuracy and regional fairness through O-RIS configuration. Methods Under the far-field channel model, O-RIS orientation optimization is formulated as a received-power maximization problem. A positioning algorithm that combines Particle Swarm Optimization (PSO) with the N-step positioning algorithm is proposed. This method dynamically adjusts O-RIS orientation without prior knowledge of the receiver position. Under the near-field channel model, the allocation problem between O-RIS elements and Light-Emitting Diodes (LEDs) is formulated as a Markov Decision Process (MDP). A reinforcement learning method based on experience replay and knowledge use is designed to solve this problem. The method minimizes the CRLB while maintaining positioning fairness for users in different regions. Results and Discussions Simulation results show that the proposed algorithms improve positioning performance under both channel models. In the far-field model, the PSO-based iterative algorithm dynamically optimizes O-RIS orientation and improves positioning accuracy. The convergence behavior of the N-step positioning algorithm further shows that the method approaches the theoretical CRLB under high signal-to-noise ratios (Fig. 4, Fig. 5). In the near-field model, the reinforcement learning method reduces the CRLB and improves positioning fairness across the whole area. It also reduces performance differences among users in different regions (Fig. 6, Fig. 7, Fig. 8). The MERAC-based reinforcement learning procedure for intelligent resource allocation is summarized in Algorithm 1. Conclusions CRLB optimization methods for O-RIS-assisted VLP systems are investigated under near-field and far-field channel models. In the far-field scenario, a PSO-based iterative algorithm is proposed to optimize O-RIS orientation and improve positioning accuracy without prior receiver-location information. In the near-field scenario, a reinforcement learning-based method is designed to optimize O-RIS element-LED allocation. This method minimizes the CRLB and improves regional positioning fairness. Simulation results verify the effectiveness of the proposed algorithms under both models. Future work may consider more practical channel impairments and multi-user scenarios to improve system robustness and scalability.

FullText(HTML)

References(30)

References

[1]	JOVICIC A, LI Junyi, and RICHARDSON T. Visible light communication: Opportunities, challenges and the path to market[J]. IEEE Communications Magazine, 2013, 51(12): 26–32. doi: 10.1109/MCOM.2013.6685754.
[2]	ZHUANG Yuan, HUA Luchi, QI Longning, et al. A survey of positioning systems using visible LED lights[J]. IEEE Communications Surveys & Tutorials, 2018, 20(3): 1963–1988. doi: 10.1109/COMST.2018.2806558.
[3]	Markets and Markets. Indoor location market by component (hardware, solutions, and services), technology (BLE, UWB, Wi-Fi, RFID), application (emergency response management, remote monitoring), organization size, vertical, and region - global forecast to 2026[EB/OL]. https://www.marketsandmarkets.com/Market-Reports/indoor-location-market-989.html, 2021.
[4]	Grand View Research Inc. Visible Light Communication (VLC)/Light fidelity (Li-Fi) market analysis by component (LED, Photodetector, Microcontroller), by application (retail, automotive & transportation, consumer electronics, healthcare, defense & security and aviation) and segment forecasts to 2024[EB/OL]. https://www.grandviewresearch.com/industry-analysis/visible-light-communication-market, 2016.
[5]	PETROSINO A, STRICCOLI D, ROMANOV O, et al. Light fidelity for internet of things: A survey[J]. Optical Switching and Networking, 2023, 48: 100732. doi: 10.1016/j.osn.2023.100732.
[6]	BOZANIS D, EVGENIDIS N G, PAPANIKOLAOU V K, et al. Indoor 3D visible light positioning analysis with channel estimation errors[C]. 2023 30th International Conference on Systems, Signals and Image Processing (IWSSIP), Ohrid, North Macedonia, 2023: 1–4. doi: 10.1109/IWSSIP58668.2023.10180234.
[7]	MA Shuai, LI Bing, ZHANG Guanjie, et al. Centimeter-level 3-D mobile online visible light positioning system with single LED lamp[J]. IEEE Internet of Things Journal, 2024, 11(1): 418–429. doi: 10.1109/JIOT.2023.3285556.
[8]	CAO Xiaoxiang, ZHUANG Yuan, CHEN Guoliang, et al. A visible light positioning system based on a particle filter and deep learning[J]. IEEE Transactions on Aerospace and Electronic Systems, 2024, 60(3): 2735–2748. doi: 10.1109/TAES.2023.3293781.
[9]	LIU Ren, LIANG Zhonghua, YANG Kuo, et al. Machine learning based visible light indoor positioning with single-LED and single rotatable photo detector[J]. IEEE Photonics Journal, 2022, 14(3): 7322511. doi: 10.1109/jphot.2022.3163415.
[10]	SUN Xiao, ZHUANG Yuan, HUAI Jianzhu, et al. RSS-based visible light positioning using nonlinear optimization[J]. IEEE Internet of Things Journal, 2022, 9(15): 14137–14150. doi: 10.1109/JIOT.2022.3156616.
[11]	AKIYAMA T, SUGIMOTO M, and HASHIZUME H. Time-of-arrival-based smartphone localization using visible light communication[C]. 2017 International Conference on Indoor Positioning and Indoor Navigation (IPIN), Sapporo, Japan, 2017: 1–7. doi: 10.1109/IPIN.2017.8115904.
[12]	SONER B and COLERI S. Visible light communication based vehicle localization for collision avoidance and platooning[J]. IEEE Transactions on Vehicular Technology, 2021, 70(3): 2167–2180. doi: 10.1109/TVT.2021.3061512.
[13]	LI Zhengpeng, QIU Guodong, ZHAO Lei, et al. Dual-mode LED aided visible light positioning system under multi-path propagation: Design and demonstration[J]. IEEE Transactions on Wireless Communications, 2021, 20(9): 5986–6003. doi: 10.1109/TWC.2021.3071469.
[14]	ZHANG Kehan, ZHANG Zaichen, and ZHU Bingcheng. Beacon LED coordinates estimator with selected AOA estimators for visible light positioning systems[J]. IEEE Transactions on Wireless Communications, 2024, 23(3): 1713–1727. doi: 10.1109/TWC.2023.3291416.
[15]	ABOAGYE S, NDJIONGUE A R, NGATCHED T M N, et al. RIS-assisted visible light communication systems: A tutorial[J]. IEEE Communications Surveys & Tutorials, 2023, 25(1): 251–288. doi: 10.1109/COMST.2022.3225859.
[16]	ABOAGYE S, NGATCHED T M N, DOBRE O A, et al. Intelligent reflecting surface-aided indoor visible light communication systems[J]. IEEE Communications Letters, 2021, 25(12): 3913–3917. doi: 10.1109/LCOMM.2021.3114594.
[17]	GUZMAN B G, CESPEDES M M, JIMENEZ V P G, et al. Resource allocation exploiting reflective surfaces to minimize the outage probability in VLC[J]. IEEE Transactions on Wireless Communications, 2025, 24(7): 5493–5507. doi: 10.1109/twc.2025.3547648.
[18]	AN Nan, YANG Fang, CHENG Ling, et al. IRS-assisted aggregated VLC-RF system: Resource allocation for energy efficiency maximization[J]. IEEE Transactions on Wireless Communications, 2024, 23(10): 12578–12593. doi: 10.1109/TWC.2024.3393621.
[19]	ABDELHADY A M, SALEM A K S, AMIN O, et al. Visible light communications via intelligent reflecting surfaces: Metasurfaces vs mirror arrays[J]. IEEE Open Journal of the Communications Society, 2021, 2: 1–20. doi: 10.1109/OJCOMS.2020.3041930.
[20]	SUN Shiyuan, YANG Fang, SONG Jian, et al. Intelligent reflecting surface for MIMO VLC: Joint design of surface configuration and transceiver signal processing[J]. IEEE Transactions on Wireless Communications, 2023, 22(9): 5785–5799. doi: 10.1109/TWC.2023.3236811.
[21]	SUN Wenjing, CHEN Jian, and YU Cangyuan. Indoor receiving signal strength based visible light positioning enabled with equivalent virtual lamps[J]. Applied Optics, 2023, 62(17): 4583–4590. doi: 10.1364/AO.482797.
[22]	KOKDOGAN F and GEZICI S. Intelligent reflecting surfaces for visible light positioning based on received power measurements[J]. IEEE Transactions on Vehicular Technology, 2024, 73(9): 13108–13121. doi: 10.1109/TVT.2024.3390178.
[23]	KAHSAY L Z, NASER S, ELDEEB H B, et al. O-RIS assisted NOMA-VLC system: Integrated positioning and communications[J]. IEEE Wireless Communications Letters, 2025, 14(9): 2703–2707. doi: 10.1109/LWC.2025.3576717.
[24]	胡文学, 王泽华, 余成, 等. 基于平面扩展和约束优化的激光惯性SLAM方法[J]. 光电工程, 2024, 51(4): 230279. doi: 10.12086/oee.2024.230279. HU Wenxue, WANG Zehua, YU Cheng, et al. A laser inertial SLAM approach based on planar expansion and constrained optimization[J]. Opto-Electron Engineering, 2024, 51(4): 230279. doi: 10.12086/oee.2024.230279.
[25]	易卿武, 黄璐, 蔚保国, 等. 面向室内地下遮蔽空间的定位可信性提升方法[J]. 电子与信息学报, 2025, 47(5): 1529–1542. doi: 10.11999/JEIT240870. YI Qingwu, HUANG Lu, WEI Baoguo, et al. Methods for enhancing positioning reliability in indoor and underground satellite-shielded environments[J]. Journal of Electronics & Information Technology, 2025, 47(5): 1529–1542. doi: 10.11999/JEIT240870.
[26]	MARINI F and WALCZAK B. Particle swarm optimization (PSO). A tutorial[J]. Chemometrics and Intelligent Laboratory Systems, 2015, 149: 153–165. doi: 10.1016/j.chemolab.2015.08.020.
[27]	KUMAR A M S, PARTHIBAN K, and SHANKAR S S. An efficient task scheduling in a cloud computing environment using hybrid Genetic Algorithm-Particle Swarm Optimization (GA-PSO) algorithm[C]. 2019 International Conference on Intelligent Sustainable Systems (ICISS), Palladam, India, 2019: 29–34. doi: 10.1109/ISS1.2019.8908041.
[28]	SHI Y and EBERHART R C. Empirical study of particle swarm optimization[C]. The 1999 Congress on Evolutionary Computation-CEC99 (Cat. No. 99TH8406), Washington, USA, 1999: 1945–1950. doi: 10.1109/CEC.1999.785511.
[29]	SUTTON R S and BARTO A G. Reinforcement Learning: An Introduction[M]. Cambridge, USA: MIT Press, 1998.
[30]	YANG Helin, DU Pengfei, ZHONG Wende, et al. Reinforcement learning-based intelligent resource allocation for integrated VLCP systems[J]. IEEE Wireless Communications Letters, 2019, 8(4): 1204–1207. doi: 10.1109/LWC.2019.2911682.
