Component Placement Algorithm Considering Reagent Type Differences in Cell Reuse for FPVA Biochips

XU Yanbo; ZHU Yuhan; HUANG Xing; LIU Genggeng

doi:10.11999/JEIT250731

Article Contents

Article Navigation > Journal of Electronics & Information Technology > 2026 >

XU Yanbo, ZHU Yuhan, HUANG Xing, LIU Genggeng. Component Placement Algorithm Considering Reagent Type Differences in Cell Reuse for FPVA Biochips[J]. Journal of Electronics & Information Technology. doi: 10.11999/JEIT250731

Citation:

XU Yanbo, ZHU Yuhan, HUANG Xing, LIU Genggeng. Component Placement Algorithm Considering Reagent Type Differences in Cell Reuse for FPVA Biochips[J]. Journal of Electronics & Information Technology. doi: 10.11999/JEIT250731

Citation:

PDF( 2018 KB)

Component Placement Algorithm Considering Reagent Type Differences in Cell Reuse for FPVA Biochips

doi: 10.11999/JEIT250731 cstr: 32379.14.JEIT250731

XU Yanbo^{1, 2, 3},
ZHU Yuhan^{1, 2, 3},
HUANG Xing⁴,
LIU Genggeng^{1, 2, 3
,
,}

1.
College of Computer and Data Science, Fuzhou University, Fuzhou 350116, China
2.
Engineering Research Center of Big Data Intelligence, Ministry of Education, Fuzhou 350116, China
3.
Fujian Key Laboratory of Network Computing and Intelligent Information Processing, Fuzhou 350116, China
4.
School of Computer Science, Northwestern Polytechnical University, Xi’an 710072, China

Funds: The National Natural Science Foundation of China(62372109, 62572396), The Fujian Science Fund for Distinguished Young Scholars(2023J06017)

Accepted Date: 2026-01-12
Rev Recd Date: 2026-01-12

Available Online: 2026-01-27

Abstract

Abstract

Objective Fully Programmable Valve Array (FPVA) biochips, as a novel type of flow-based microfluidic biochips, offer exceptional flexibility and programmability, enabling them to meet diverse and complex experimental requirements. Among the various stages of FPVA architectural synthesis, component placement design plays a critical role, as it directly impacts several key performance metrics, including the completion time of the bioassay, the total length of the fluid transport path, and the degree of cross-contamination. As an important manifestation of FPVA's flexibility and programmability, cell reuse requires special attention during the component placement process. However, existing FPVA component placement research has largely overlooked the impact of reagent type differences in cell reuse on these performance indicators. Methods This paper presents a component placement algorithm for FPVA biochip that takes into account the differences in reagent types during cell reuse. First, by considering the influence of reagent-type differences and component overlap on cross-contamination, this proposed algorithm introduces a cell reuse complexity metric to quantify the complexity of cell reuse in component placement solutions. Second, the proposed algorithm incorporates constraints, including component placement area restrictions and non-overlapping constraints for concurrent components, to ensure the validity of component placement solutions. Finally, the proposed algorithm optimizes the reward function to minimize cell reuse complexity and reduce the distance between components using the same type of reagent. The proposed algorithm aims to minimize cross-contamination, the total length of the fluid transport path, and the completion time of the bioassay in the final component placement. Results and Discussions The proposed algorithm conducts simulation experiments on benchmark FPVA instances with varying chip sizes and functional requirements, comparing the proposed algorithm with existing related methods. Results show that the proposed algorithm achieves an average reduction of 34.2% in cell reuse complexity, 2.8% in the completion time of the bioassay, and 9.2% in the total length of the fluid transport path (Table 2), while also reducing the reagent-aware distance metric by an average of 29.9% (Fig. 6). The decision trajectories of the learning agent demonstrate clear spatial regularity, highlighting the model's awareness of global placement structures. Conclusions This paper is the first to investigate the component placement problem of FPVA biochips considering reagent type differences in cell reuse. The main contributions and findings are as follows: (1) A cell reuse complexity metric is designed to measure the degree of cell reuse in component placement. (2) The FPVA component placement task is effectively modeled as a Markov decision process, enabling the use of double deep Q-networks to learn efficient and safe component placement policies. (3) Compared with existing work, the proposed model significantly improves the biochemical assay performance and reliability of FPVA biochips.
